Description
A Versatile Control Hub for Home Audio Systems
Easily connect up to three audio sources and switch inputs instantly with the remote for seamless audio control.
3 In / 3 Out, Effortless Switching
Equipped with three input ports: RCA 1, RCA 2, XLR and three output ports: RCA, XLR, Sub-Out, which makes it easy to connect multiple audio sources for a truly flexible listening experience.
Aluminum-Alloy Compact Design
Metallic texture, series design and refined, with enhanced resistance to electromagnetic interference.
12V Trigger In/Out
Enables synchronized on/off with audio setups, such as the ZD3/ZA3, automating system control for seamless.
HPF Adjustment
Offers three levels of high-pass filtering: 20Hz-20kHz, 80Hz-20kHz,120Hz-20kHz. Ensures that only the high-frequency part is sent to the main speakers, enhancing vocal clarity and detail resolution.
Multi-Function IR Control
Easily adjust the volume, switch sources, and control the power on/off without leaving your seat, with the remote control that can be used for multiple Fosi Audio.
Versatile
Sound Tuning Options
| Bypass | Bass and Treble Control | Balance Adjustment | Volume Memory |
|---|---|---|---|
| Enjoy a very clean, noise-free listening experience by bypassing the tone control circuit. | Achieve personalized tuning with a midpoint reference for better sound customization. | Adjust the volume balance between the left and right channels. | Automatically remembers the volume level for each input source. When switching sources, it adjusts to your previous level—making your HiFi system smarter and more user-friendly. |
Specifications
| Specification | Detail |
|---|---|
| Dimensions | 239mm × 164mm × 54mm |
| Channel | 2.0 |
| Input | RCA ×2, XLR |
| Output | RCA, XLR, SUB |
| Bass and Treble Control Range | Treble: ±6dBBass: ±12dB |
| Input Voltage Range | AC 110–240V |
Frequency Response
| Mode | Response |
|---|---|
| XLR / RCA | 20Hz – 20kHz (±0.2dB) |
| HPF 80Hz | 80Hz – 20kHz (±0.2dB) |
| HPF 120Hz | 120Hz – 20kHz (±0.2dB) |
| Sub Output | 20Hz – 200Hz (±0.2dB) |
Balanced Output (XLR)
| Specification | Detail |
|---|---|
| SNR | ≥ 112dB |
| Dynamic Range | ≥ 112dB |
| THD+N | ≤ 0.0007% |
| Noise Floor | ≤ 6µV |
Single-Ended Output (RCA)
| Specification | Detail |
|---|---|
| SNR | ≥ 115dB |
| Dynamic Range | ≥ 115dB |
| THD+N | ≤ 0.0008% |
| Noise Floor | ≤ 4µV |
