Description
Clean and stable power. By opting for a fully battery powered design, M30 gets the cleanest and most stable power in all conditions. Providing the best sound quality without any need for additional power conditioning. Powerful and clean sound. Designed with newly designed I/V conversion stage and in-house developed CPAF lowpass filtering technology. It’s one of our most versatile amplifiers, working smoothly with sensitive earphones, yet powerful enough for the most demanding audiophile headphones.
General
- Dimension: 213 x 258 x 50 mm / Weight: 3kg
- Screen: 6 inch 1920 x 1080 IPS touch screen
- Operating System: Closed Android, with deeply customised to prioritise highest quality audio playback
- Storage: up to 2TB Micro SD card (purchased separately)
Headphone Section
- Output: 500mW (single ended) / 1530mW (balanced)
- Output impedance: 0.8 Ohm (single ended) / 1.6 Ohm (balanced)
- Channel separation: 71 dB (single ended) / 107dB (balanced)
- Recommended headphone impedance: 8-300 ohms
- Distortion: 0.00045%
- Signal to Noise Ratio: 123 dB @ 32 ohm (A-weighting)
- Dynamic Range: > 123 dB @ 32 ohm (A-weighting)
- Output port: 6.3mm, 3.5mm (single ended) / 2.5mm, 3.5mm Pro, 4.4mm (balanced) / XLR (balanced)
- Selectable tube section: 2 x Korg 6P1 tubes
DAC Section
- DAC Model: AKM AKK4497 x 2
- Sampling rate: up to 768kHz / 32 bit, Native DSD512 Software
- USB input: connect to use as sound device for external transport such as computer or tablet/phone
- USB Host port for external HDD connectivity
- USB output for connection to external DAC
- Digital Coaxial and Optical inputs
Streaming Section
- DLNA/UPNP/Airplay network connectivity
- 2-way Bluetooth, stream from a source over bluetooth, or stream from EM5 to bluetooth headphones
- Bluetooth Codecs: LDAC, LHDC, aptX (trasmit); LDAC. SBC (receive)
- Spotify, Tidal, Qobuz, QQ music, Deezer, Amazon Music apps available
- MQA support 8x playback from stored files, streaming apps andUSB input
- Ethernet port
- 2.5G / 5G Dual Band Wifi
- OTA firmware updates
- Shanling Eddict Player app gives complete control on smartphones and tablets
Preamp / Output Section
- Analogue XLR balanced outputs
- Analogue RCA outputs
- Alanlogue RCA input for AUX analogue sources
- Digital Coaxial and Optical outputs
- Hi-Res Audio and Hi-Res Wireless Audio Certifications from the Japan Audio Society
Power Section
- 16500 mAh rechargeable battery module, with selectable charging thresholds for ‘always on battery’ playback
