Description
Turntable
With tracking force, anti-skate and cartridge position preset at the factory, the McIntosh MT10 delivers high performance LP playback with minimal set up. A custom tonearm features a rigid, dural-aluminum arm-tube gimbaled in two sapphire (horizontal) and two ceramic (vertical) bearings for the least possible friction. A .5mV moving coil cartridge is included, and features an ebony body with an elliptical stylus. Enjoy a greater level of music with the McIntosh MT10.
Specifications
CARTRIDGE SPECIFICATIONS
- CARTRIDGE TYPE Moving Coil, Low Output
- OUTPUT LEVEL 0.5 mV at 5 cm/s
- LOAD IMPEDANCE 400 to 500 Ohms recommended
- FREQUENCY RESPONSE 20Hz to 50kHz
- CHANNEL SEPARATION Greater than 30dB at 1Khz
- COMPLIANCE 6 x 10-6 cm/dyne
- RECOMMENDED TRACKING FORCE 2.4 g
- CHANNEL DIFFERENCE Less than 0.3 dB at 1kHz
- TOTAL MASS 11 g
- STYLUS Elliptical Diamond
- CANTILEVER MATERIAL Aluminum
TONEARM SPECIFICATIONS
- BEARING Sapphire and Ceramic
- ARM TUBE Dural-Aluminum
- COUNTERWEIGHT Eccentric
- ADJUSTMENTS VTA, Antiskate, Azimuth
TURNTABLE SPECIFICATIONS
- PLAYBACK SPEEDS 33 1/3, 45 and 78 rpm
- MOTOR TYPE DC Brushless
- SPEED CONTROL Electronic w/ braking feature
- PLATTER Silicon Acrylic
- PLATTER BEARING Magnetic Suspended Ceramic
CONNECTIVITY
- STEREO OUTPUTS UNBALANCED 1
CONTROL
- POWER CONTROL INPUT Yes
- POWER CONTROL OUTPUT Yes
- PLATTER LIGHT Yes
- SPEED CONTROL FINE ADJUSTMENT Yes
GENERAL SPECIFICATIONS
- DUST COVER No
WEIGHTS & DIMENSIONS
- DIMENSIONS (W X H X D) 17-1/2″ (44.45cm) x 8-13/16″ (22.38cm) x 21″ (53.34cm) Note: Tone Arm Height will vary depending on the type of Cartridge installed.
- WEIGHT 42 lbs (19 kg)
