Description
Features:
- The Sonance OMNI-6T is an Omnidirectional 70V/100V/8 Ohm loudspeaker, designed to deliver 360-degree coverage in applications such as resort gardens, hotel pool areas, theme parks and outdoor shopping malls.
- The OMNI-6T features a unique 2-way design, consisting of one high-excursion 6.5″ woofer and four 1.25″ wide band drivers, providing best-in-class frequency response.
- The Sonance Laminated Core Transformer delivers un-compromised fidelity in 70V/100V.
- The textured dark brown enclosure is designed to blend into ground cover, garden beds and foliage.
Specifications:
- Frequency Range (-10dB) 38Hz – 25khz
- Frequency Range (-3dB) 60Hz – 20kHz
- Power Capacity 120 Watts Continuous Program Power, 60 Watts Continuous Pink Noise
- Nominal Sensitivity 88 dB
- Nominal Coverage Angle 360 degrees horizontal, 160 degrees vertical
- Directivity Factor (Q) 2.2
- Directivity (DI) 3.4dB
- Rated Maximum SPL 107dB @ 1 meter (3.3 feet) average, 113dB peak
- Rated Impedance 8 ohms nominal, 6 ohms minimum
- Transformer Taps 80W, 40W, 20W and (10W @70V)
- Crossover Point 500Hz
- LF Driver 6.5″ (165mm) Polypropylene Cone, Santoprene Rubber Surround
- Wide Band Driver Four 1.25″ (32mm) EPDM dome, Ferrofluid cooled
- Input Connectors Flying Leads
- Environmental Conforms to Mil Spec 810 for humidity, salt spray, temperature and UV, IEC 529, IP-66 waterproof rating
- Included Accessories Silicone filled wire nuts
- Overall Dimension HxDia 14.5”x 12″ (368mm x 305mm)
- Net Weight 14.60 lbs (6.62kg) each
- Shipping Weight 23.25 lbs (10.55kg) each
Shared Specifications:
Top Diameter
12″ (305mm)
Base Diameter
11.36″ (289mm)
Height
14.5″ (368mm)
