Description



5.1.1 Power Amplifier
Gain.....................................................................................................................................................................30
THD.........................................................................................................................................................< 0,005%
Signal-to-noise ratio ............................................................................................................................... > 95dB
Input sensitivity (2x550W, 4 ohm)............................................................................................................ 1,2V
Output power.........................................................................................................................2x 550W (4 ohm)
5.1.2 Analog Preamplifier
Input impedance (RCA)..............................................................................................................................10kΩ
Input impedance (XLR)..............................................................................................................................20kΩ
Output impedance (RCA: PRE, LINE) ........................................................................................................47Ω
Output impedance (XLR).............................................................................................................................94Ω
Gain.......................................................................................................................................................................1
THD........................................................................................................................................................... < 0,02%
Signal-to-noise ratio ............................................................................................................................... > 99dB
Crosstalk (channels) ............................................................................................................................ > 102dB
Crosstalk (inputs).................................................................................................................................... > 88dB
Input level (1% THD).................................................................................................................................... 4,3V
Output level PRE OUT (1% THD).............................................................................................................. 5,4V
Output level LINE OUT ................................................................................................................................ 2,5V
Frequency response (-3dB)............................................................................................... < 5Hz bis > 30kHz
5.1.3 Headphone Amplifier
Output impedance .......................................................................................................................................2,5Ω
Gain....................................................................................................................................................................3,0
THD.........................................................................................................................................................< 0,002%
Signal-to-noise ratio ............................................................................................................................... > 97dB
Output level (1% THD).................................................................................................................................... 9V
5.1.4 Phono Preamplifier
RIAA equalization (20Hz-20kHz).......................................................................................................+/- 0,3dB
Gain MM .....................................................................................................................40dB, 45dB, 50dB, 55dB
S/N ratio MM ...................................................................................................................................... > 84dB(A)
Gain MC ......................................................................................................................55dB, 60dB, 65dB, 70dB
S/N ratio MC........................................................................................................................................ >75dB(A)
Input level MM (1% THD, 40dB) ............................................................................................................ 76 mV
Input level MC (1% THD, 60dB) ............................................................................................................ 7,4 mV
Frequency response (Line-Out).............................................................................................11Hz – 100kHz
Adjustable MC impedance (Ω) ....................................................................100; 180; 220; 330; 660; 1k; 2k
Adjustable MM capacitance (pF).............................................................47; 100; 150; 200; 270; 310; 410

5.1.5 Network
LAN port (hot plug).......................................................................................................................... 100 Mbit/s
Supported WLAN standards........................................................................ 2,4/ 5GHz/ 802.11a/b/g/n/ac
Number of antennas: ........................................................................................................................................2
WPS ................................................................................................................................................................. Yes
5.1.6 Streaming
Integrated DAC (Modular) ................................................................................AVM DAC-S: ESS 9038 PRO
Max sample rates .......................................................................................... DSD256, 32 Bit/384 kHz PCM
Streaming services.................................... AirPlay, Qobuz, Roon, Spotify, TIDAL (MAX), HighResAudio
Supported file formats.............................................WAV, MP3, WM, AAC, FLAC, ALAC, DSD, Ogg, AIFF
5.1.7 USB-A Input
USB-Standard .........................................................................................................................................USB 2.0
Max current.............................................................................................................................................500 mA
Supported formats ........................................................................................................FAT16, FAT32, NTFS
Note: USB-A is for hard drives and USB sticks only!
5.1.8 USB-C Input
USB-Standard .........................................................................................................................................USB 2.0
Voltage.............................................................................................................................................................. 5V
Supported devices ........................................................................................... Windows PC, MacOS-Geräte
Supported formats .............................................................................bis zu DSD256, 32 Bit/384 kHz PCM
Note: USB-C is for end devices like computers only!

5.1.9 Digital Inputs (S/PDIF Coaxial/Optical)
Max sampling rate (Optical) ................................................................................................... 96 kHz / 24 Bit
Max sampling rate (Coaxial).................................................................................................192 kHz / 24 Bit
Min signal level at 192kHz (Coax) .............................................................................................. > 150 mVpp
Input impedance (Coax).............................................................................................................................75 Ω
Deemphasis ...............................................................................................................................Yes, automatic

5.1.10 Digitale Outputs
Max sampling rate (Optical) ................................................................................................... 96 kHz / 24 Bit
Max sampling rate (Coaxial).................................................................................................192 kHz / 24 Bit
Output impedance (Coax)..........................................................................................................................75 Ω
Note: Cable length should not exceed 3 meters.
5.1.11 Bluetooth
Bluetooth-Standard ........................................................................................................................................5.0
Supported profiles ............................................................................................................... AVRCP 1.5, AD2P
5.1.12 Control
Trigger- input ............................................................................................................................................. 5-20V
Trigger- outputs (2x).....................................................................................................................................12V
External IR input...................................................................................................................................Available
Note: Use standard 3.5mm mono jack for trigger. Trigger outputs have 1-second delay.
5.1.13 Power Supply (CS and AS models only)
Voltage.......................................................................................................................100V-240V / 50Hz-60Hz
Standby consumption.......................................................................................................................< 1,0 Watt
Network standby...................................................................................................................................< 4 Watt
Idle power.............................................................................................................................................< 35 Watt
Max power.......................................................................................................................................... 1000 Watt
Fuse (power amp).....................................................................................................................................T 6,3A
5.1.14 General
Weight.......................................................................................................................................................... 15 kg
Dimensions (W x H x D)......................................................................................................... 430 x 122 x 350
Warranty .......................................................................................2 years + 2 years with online registration
.........................................................................................................................(warranty may vary by country)



Additional information

Color

Black, Silver, Cellini
