Description
AKM AK4493EQ DAC | CPAF Low-Pass Filtering | Closed Android System | AGLO Technology | 6.35mm Headphone Output | Speaker output 50 W @ 4 Ohm per channel. Running deeply customized closed Android system, EA5 serves as a standalone music system. No need for computer or complicated setting up, just direct access to your music collection and streaming services. Supported services: Apple Music / Spotify /
Tidal / Deezer/ Qobuz / Amazon Music
Specifications
General
- Dimension: 238 x 188 x 55 mm
- Screen: 4.7 inch 720 x 1280 IPS touch screen
- Operating System: Closed Android, with deeply customised to prioritise highest quality audio playback
- Storage: up to 2TB Micro SD card (purchased separately)
Speaker Output Section
- Output Power: 2 x 50w @ 4 ohm / 2 x 32w @ 8 ohm
- Frequency Response: 20Hz – 20kHz (-0.5dB Standard Mode)
- THD+N: 0.003% (A-Weighted @ 0.5V)
- Signal to Noise Ratio: 107 dB @ 8 ohm (A-Weighting)
- Noise: 83dB @ 8ohm (A-Weighting)
- Channel Seperation: 68 dB @ 8 ohm
Headphone Section
- Output: 570mW (single ended)
- Output impedance: 0.8 Ohm (single ended)
- Channel separation: 75 dB (single ended)
- Recommended headphone impedance: 8-300 ohms
- Distortion: 0.0024%
- Signal to Noise Ratio: 118 dB @ 32 ohm (A-weighting)
- Dynamic Range: > 112 dB @ 32 ohm (A-weighting)
- Output port: 6.3mm (single ended)
DAC Section
- DAC Model: AK4493EQ
- Sampling rate: up to 768kHz / 32 bit, Native DSD512 Software
- USB input: connect to use as sound device for external transport such as computer or tablet/phone
- USB Host port for external HDD connectivity
- Digital Coaxial and Optical inputs
Streaming Section
- DLNA/UPNP/Airplay network connectivity
- 2-way Bluetooth, stream from a source over bluetooth, or stream from EM5 to bluetooth headphones
- Bluetooth Codecs: LDAC, LHDC, SBC, aptX (trasmit); LDAC. SBC (receive)
- Spotify, Tidal, Qobuz, QQ music, Deezer, Amazon Music apps available
- MQA support 8x playback from stored files, streaming apps and USB input
- Ethernet port
- 2.5G / 5G Dual Band Wifi
- OTA firmware updates
- Shanling Eddict Player app gives complete control on smartphones and tablets
Analogue Section
- Analogue RCA input
- Analogue RCA output
