Description
To provide the highest sound quality, MCD1.3 includes two independent power supply systems. Providing clean and stable power for its DAC and analog circuits, while the system functions run on their fully separated power
supply, for total elimination of any interferences.
Based on a proven Philips SAA7824 drive and a new Sanyo DA11 laser, MCD1.3 offers top-quality CD drive playback. Error-free and smooth reading of all discs for the best sound quality.
Specifications
Dimensions: 280 X 280 X 96mm (L x W x H)
Weight: 5.7kg
Power Supply: Dedicated Transformer & 5V Power Module
Processor: Ingenic X2000
DAC: AKM AK4499EX & AK4191EQ DAC System
USB Input: XMOS XU316
Bluetooth: Bluetooth 5.0 Receiver
Bluetooth Codec Support: LDAC, aptX HD, aptX, AAC, SBC
Display: 5.1-inch LG Touch Screen (854*358)
Controls: Touch Screen, Physical buttons + Volume Wheel, Remote Control, Companion app for iOS & Android
Inputs: CD, USB Drive, USB DAC, Bluetooth, Wi-Fi, SPDIF Coaxial & Optical
Digital Outputs: 12S, SPDIF Coaxial & Optical
Analog Outputs: XLR, RCA & 6.35mm Headphone Out USB Drive Audio Formats Support: DSD (“.iso”, “.dsf”, “.dff”, does not support “DST”) / ISO / DXD / APE / FLAC / WAV / AIFF / AIF / DTS / MP3 / WMA / AAC / OGG /
ALAC / MP2/M4A/AC3/M3U/M3U8/OPUS
USB Drive Hi-Res Support: 32bit/768kHz, DSD512 Native
USB DAC Hi-Res Support: 32bit/768kHz, DSD512 Native
Coaxial/ Optical Input: 24bit/192kHz
Coaxial/ Optical Output: 24bit/192kHz
RCA output:
Output level: 2.5Vrms
Frequency Response: 20Hz-40kHz (-0.1dB)
THD+N: 0.0005%
Dynamic Range: 119dB
Signal-to-noise ratio: 119dB
